BHARAT 101
4G With CAN
AIS140 Certified 4G Telematics Tracking Device. BHARAT101-4G can be described as a High-end Compact Vehicle tracking/Fleet management black box with rugged IP65 casing and representing next generation communication technology.
Overview
Bharat 101 PLUS 4G is an AIS140 Certified 4G Telematics Tracking Device. BHARAT101-4G can be described as a High-end Compact Vehicle tracking/Fleet management black box with rugged IP65 casing and representing next generation communication technology. The 4G enabled device comes with lots of interface options, speed processing power. It can be used as a fleet management device in various domains such as Logistics, taxi operation, car/bike rentals, security tracking, insurance telematics, asset tracking, etc. integrated with internal antennae which makes it suitable for hidden/stealth installations.
IP67 Rating - Waterproof & Dustproof
AIS 140 Certification
All Parameter Configuration through SMS & USB
Main Battery Removal Alert
Motion Sensor, Accelerometer, Gyroscope
Automotive ECU Type Connector
Long Battery Backup up to 8 hrs
2 Analog Inputs, 5 Digital Inputs & 2 Digital Outputs
Data Storage With Storage Capacity Of 40000 Records)
Remote Health Checking Through SMS
Low power consumption & power optimization
Interface : 1x RS232; 1x RS485
Fleet Management
Automobile OEMs
Compliance Market
Immobilization Relay
RFID Reader
Panic Button
Fuel Sensor
| Features | Particulars | ||
|---|---|---|---|
| Cellular | 2G | 900/1800 MHz | |
| LTE-Cat1 | B1, B3, B5, B8, B34, B39, B40, B41 | ||
| Short Range | BLE | 5 | |
| Navigation | GNSS | GPS+IRNSS | |
| External | AIN | 2 Nos | |
| Interfaces | DOUT | 2Nos | |
| (300mA Low Side Drive) | |||
| DIN | 5 Nos | ||
| RS232 | 1No | ||
| RS485 | 1No | ||
| Wake-up Sources | IGN | Yes | |
| Panic | Yes | ||
| ACC | Yes | ||
| Power | Yes | ||
| Tamper | Yes | ||
| Indications (GPS, Process, NetLight, Power) | 4Nos | ||
| Power Supply | 8-32V DC | ||
| Sleep mode Current | <5mA | ||
| Internal Battery | 850mAH | ||
| LTE Antenna | Internal PCB | ||
| GNSS Antenna | Internal Ceramic Patch Antenna | ||
| BLE Antenna | Internal PCB | ||
| Sensors | Accelerometer and Gyro | ||
| SIM | eSIM and NanoSIM | ||
| Data Storage -1 | 16MB | ||
| Load Dump | ISO 7637-2 Pulse 5a, 5b | ||
| EMI/EMC | AIS-004 | ||
| Enclosure | Plastic | ||
| ESD Protection | 8kV | ||
| IP | IP65 | ||
| Operating Temp | -25 to +85deg | ||
| Storage Temp | -40 to +85deg | ||
| Battery capacity | 800mAH | ||
| Vibration | Frequency 5 – 40 Hz, Acceleration 3G condition, Duration 100 hours (Test duration shall be 32 h for each plane) | ||
| High Temperature Operating Endurance | ISO 16750-4, Clause 5.1.2.2 | ||
| Thermal Shock | ISO 16750-4 | ||
| Mechanical shock | ISO16750-3,500m/s^2, 6ms, 15G at 10 shocks per test direction | ||
