Teltonika FMB209
2G tracker with RS232 interface certified for transport in India
Overview
2G tracker with RS232 interface certified for transport in India
Extended product usage scenarios
RIP65 Rating - Waterproof & Dustproof
Certified For Transport
Fuel Monitoring
Remote Logistic Tracking
Corporate Car Sharing
Waste Container Tracking
| Parameters | Description |
|---|---|
| Technology | GSM/GPRS/GNSS/BLUETOOTH |
| GNSS | GPS, NavIC(IRNSS), GLONASS, GALILEO, BEIDOU, QZSS |
| Receiver | L1 and L5 dual-band GNSS receiver |
| Tracking sensitivity | -162 dBM |
| Position Accuracy | < 2.5 m CEP |
| Hot start | < 1.5 s |
| Warm start | < 25 s |
| Cold start | < 32 s |
| Technology | GSM |
| 2G bands | Quad-band 850 / 900 / 1800 / 1900 MHz |
| Data transfer | GPRS Multi-Slot Class 12 (up to 240 kbps), GPRS Mobile Station Class B |
| Data support | SMS (text/data) |
| Input voltage range | 10–30 V DC with overvoltage and reverse polarity protection |
| Internal Back-up battery | 800 mAh Li-Ion battery (0.49 Wh) |
| Power consumption | At 12V < 1.4 mA (Ultra Deep Sleep) |
| At 12V < 3.9 mA (Deep Sleep) | |
| At 12V < 4.6 mA (Online Deep Sleep) | |
| At 12V < 7.1 mA (GPS Sleep) | |
| At 12V < 28.3 mA (nominal) | |
| Specification | 4.0 + LE |
| Supported peripherals | Temperature and Humidity sensor, Headset, OBDII dongle, Inateck Barcode Scanner, Universal BLE sensors support |
| Digital Inputs | 2 |
| Digital Outputs | 2 |
| Analog inputs / Digital inputs | 2 |
| RS232 | 1 |
| GNSS antenna | Internal High Gain |
| Cellular antenna | Internal GSM High Gain |
| USB | 2.0 Micro-USB |
| LED indication | 2 status LED lights |
| SIM | eSIM |
| Memory | 128MB internal flash memory |
| Dimensions | 72,5 x 73 x 27,3 mm (L x W x H) |
| Weight | 205 g |
| Operating temperature (without battery) | -40 °C to +85 °C |
| Storage temperature (without battery) | -40 °C to +85 °C |
| Operating humidity | 5% to 95% non-condensing |
| Ingress Protection Rating | IP67 |
| Sensors | Accelerometer |
| Scenarios | Green Driving, Over Speeding detection, Jamming detection, DOUT Control Via Call, GNSS Fuel Counter, Immobilizer, Excessive Idling detection, Unplug detection, Towing detection, Crash detection, Auto Geofence, Manual Geofence, Trip |
| Sleep modes | GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep |
| Configuration and firmware update | FOTA WEB, FOTA, Teltonika Configurator (USB, Bluetooth), FMBT mobile application (Configuration) |
| SMS | Configuration, Events, DOUT control, Debug |
| GPRS commands | Configuration, DOUT control, Debug |
| Time Synchronization | GNSS, NITZ, NTP |
| Fuel monitoring | LLS (Analog), Digital LLS (RS232), OBDII dongle |
| Ignition detection | Digital Input 1, Accelerometer, External Power Voltage, Engine RPM (OBDII dongle) |
| RS232 Modes | Log Mode, NMEA, LLS, LCD, RFIH HID/MF7, Garmin FMI, TCP ASCII/Binary |
| Regulatory | EAC |
