LTE-Vehicle Tracker with BLE and Multiple Interfaces
- Multiple interfaces enable remote control and monitoring based on actionable data of ignition status
- Standard 1-wire interface available for the driver ID, detecting unauthorized private use of fleet vehicles
- Built-in BLE 5.2 grants greater expandability of a range of accessories such as BLE beacons and temperature monitoring sensors
- RS232 and RS485 serial ports enable additional functions such as fuel level monitoring
- Supports a variety of pre-integrated accessories either from Queclink or from our selected partners
BLE 5.2
RS232/RS485
1-Wire Interface
16 I/O interfaces
Insurance Telematics
Fleet Management
LTE Specifications
| Operating Band | LTE-FDD: B1/B3/B7/B8/B20/B28 |
| Data Transmission | LTE-FDD: Max 10Mbps (DL)/Max 5Mbps (UL) |
EGPRS Specifications
| Frequency | 900/1800 MHz |
| Data Transmission | EDGE: (DL) Max 236.8Kbps/(UL)Max 236.8Kbps GPRS: (DL)Max 85.6Kbps/(UL)Max 85.6Kbps |
General Specifications
| Dimensions | 94(L) x 58.5(W) x 21(H)mm |
| Weight | 92g |
| Backup Battery | Li-Polymer, 250 mAh |
| Operating Voltage | 8V to 32V DC |
| Operating Temperature | -30℃ ~ +70℃ -40℃ ~ +80℃ for storage |
| BLE | Support BLE 5.2 protocol |
GNSS Specifications
| GNSS Type | u-blox All-in-One GNSS receiver |
| Constellation Support | GPS,Glonass,Galileo,Beidou |
| Sensitivity | Cold start: -148 dBm Hot start: -160 dBm Tracking: -167 dBm |
| Position Accuracy (CEP) | Autonomous: < 2m |
| TTFF (Open Sky) | Cold start: 24s average Hot start: 1s average |
Interfaces
| Digital Inputs | 1 positive trigger input for ignition detection 4 negative trigger inputs for normal use |
| Analog Inputs | 2 analog input (0V-16V),1 analog input(0-30V) |
| Digital Outputs | 6 digital outputs |
| Latched Digital Output | 1 digital output one with internal latch circuit, open drain, 150 mA max drive current |
| Serial Port | 1 RS232 serial port on 22 pin Molex type connectors, for external devices.1 RS485 serial port on 22pin Molex type connectors, for external devices |
| Cellular Antenna | Internal only |
| GNSS Antenna | Internal antenna |
| BLE Antenna | Internal only |
| LED Indicators | Cellular network, GNSS, Power status, BLE status |
| Mini USB Interface | Used for configuration, upgrade and debug |
| 1-Wire Interface | VDD,DATA for one wire |
Air Interface Protocol
| Transmit Protocol | TCP, UDP, SMS |
| Scheduled Report | Report position and status based on preset time intervals, distance, mileage or a combination of these settings |
| Geo-fences | Geo-fence alarm and parking alarm, support up to 20 internal geo-fence regions |
| Low Power Alarm | Alarm when backup battery is low |
| Power On Report | Report when the device is powered on |
| Tow Alarm | Alarm for tow event in ignition-off state |
| Driving Behavior Monitoring | Aggressive driving behavior detection, including harsh braking, acceleration, etc. |
| Crash Detection | Accident data collection for reconstruction and analysis |
| Special Alarm | Special alarm based on digital/analog inputs |
| Remote Control | OTA control of digital outputs |
